VOICE ALARM EN54 COMMERCIAL BUSINESS MUSIC INSTALLED

NS 9048

NOISE SENSOR

8 microphones for each unit
2 units can be connected to a DXT 9000 amplifier
Suitable for ceiling and rack installation
PC software configuration

EN 54

Soporte

Características

8 microphones for each unit
2 units can be connected to a DXT 9000 amplifier
Suitable for ceiling and rack installation
PC software configuration

NS 9048 is a noise sensor that automatically adjust the volume level depending on the environment noise. It can be connected to any DXT 9000 power amplifiers and can act on every single system’s zones, measured with a variable number of microphones (up to a maximum of 8). It is specifically addressed to all those applications with a significantly different people affluence during the day. Works both with for 100 V speakers and capsule microphones.

ARCHIVED

Part number:

12399036
NS 9048
EAN 8024530014193

Especificaciones generales

Commuication bus

Serial

Units connection

J-Type fire rated

Mic inputs

Mic Phantom

+5 V DC

Input connectors

Euroblock

Configuration

PC software

Operating voltage

24 V ÷ 48 V DC

Cumplimiento estándar

Safety agency

CE compliant

Certificado EN54-16

Yes

Número de CPR

0068-CPR-002/2014

Especificaciones físicas

Material del gabinete/de la caja

Metal

Color

Black

Montaje en bastidor

1/2 19", 1U

Tamaño / Peso

Altura

43 mm / 1.69 inches

Ancho

215 mm / 8.46 inches

Profundidad

123 mm / 4.84 inches

Peso

1 kg / 2.2 lbs

Informaciones de envío

Altura de paquete

135 mm / 5.31 inches

Anchura de paquete

255 mm / 10.04 inches

Profundidad de paquete

59 mm / 2.32 inches

Peso de paquete

1.8 kg / 3.97 lbs
